EX37.5

:: EX37.5 :: Dimension
Model No. L x W (mm) Height (mm) Weight (grams) CAD
EX 37.5-10 37.5 x 37.5 9.8 14.0 By request



Material
: Aluminum 6063
Finish
: Black anodize
Remarks
:
Model number EX37.5-10 indicate 37.5×37.5mm is package footprint and 10 mm is overall height , all the dimensions are in arithmetic , the drawing overall height is real dimension


:: Rth ( oC/W ) ::
  Air Velocity / Rth ( oC/W )
  200(LFM) 400(LFM) 600(LFM)
EX37.5-10 4.83 3.45 2.70
